Layers
This option is set for how many circuit layers in your design. Please try to design your board with fewer circuit layers because multi-layer board is not cheap.
1
Separated different Design
Panelization Type
If you require panelized PCBs, you can either define it by yourself in your Gerber file or we can help you define it (for our help please select, “Custom”).
Single Board
As in My Gerber Files
Custom
Thermal Conductivity
1.0W/(m-K)
1.5W/(m-K)
2.0W/(m-K)
PCB Thickness
Board thickness tolerance is +/-10%. Solder mask and copper plating will make the boards thicker.
1.0
1.2
1.6
2.0
Solder Mask Color
Note: The silkscreen color is white for all solder mask colors except the white solder mask. For white solder masks, the silkscreen is black.
White
Black
Green
Copper Thickness
This parameter is for the Top/Bottom layer circuits’ copper weight.
1oz
2oz
3oz
Surface Finish
Extra process to exposed copper to help solderability.
HASL
HASL (Lead Free)
ENIG (Immersion Gold)
OSP
